Lenze i550 Series Project Planning Manual

Fusing data
Fusing data
Inverter i550-C0.25/230-2 i550-C0.37/230-2 i550-C0.55/230-2 i550-C0.75/230-2
Cable installaon in compliance
with
EN 60204-1
without mains choke
Circuit breaker
Characteriscs B
Max. rated current A 10 10 16 16
Fuse
Characteriscs gG/gL or gRL
Max. rated current A 10 10 16 16
with mains choke
Circuit breaker
Characteriscs B
Max. rated current A 10 10 16 16
Fuse
Characteriscs gG/gL or gRL
Max. rated current A 10 10 16 16
Earth-leakage circuit breaker
3-phase mains connecon ≥ 30 mA, type B
Fusing data
Inverter i550-C1.1/230-2 i550-C1.5/230-2 i550-C2.2/230-2 i550-C4.0/230-3
Cable installaon in compliance
with
EN 60204-1
without mains choke
Circuit breaker
Characteriscs B
Max. rated current A 25 25 25 32
Fuse
Characteriscs gG/gL or gRL
Max. rated current A 25 25 25 32
with mains choke
Circuit breaker
Characteriscs B
Max. rated current A 25 25 25 32
Fuse
Characteriscs gG/gL or gRL
Max. rated current A 25 25 25 32
Earth-leakage circuit breaker
3-phase mains connecon ≥ 30 mA, type B ≥ 300 mA, type B
Technical data
3-phase mains connecon 230/240 V
Fusing data
103

Lenze i550 Series Specifications

General

Protection Class	IP20
Ambient Temperature	-10°C to +50°C
Overload Capacity	150% for 60 seconds
Control Type	Vector control
Communication Interfaces	CANopen, Modbus, Ethernet, PROFIBUS, PROFINET
Safety	STO (Safe Torque Off)
Frequency Range	0 Hz
Cooling Method	Air cooling
Storage Temperature Range	-25°C to +70°C
Input Voltage Range	3-phase 380...480 V AC -15%/+10%
