Long Distance
Inverter RFI lter
Order code Dimensions (h x b x t) Weight
mm kg
i550-C0.37/400-3
I0FAE175F100D0000S 276 x 60 x 50 0.9i550-C0.55/400-3
i550-C0.75/400-3
i550-C1.1/400-3
I0FAE222F100D0000S 346 x 60 x 50 1.1
i550-C1.5/400-3
i550-C2.2/400-3
i550-C3.0/400-3
I0FAE255F100D0000S 346 x 90 x 60 1.7
i550-C4.0/400-3
i550-C5.5/400-3
i550-C7.5/400-3
I0FAE311F100D0000S 371 x 120 x 60 2
i550-C11/400-3
i550-C15/400-3 E84AZESR1834LD
436 x 205 x 90
7.5
i550-C18/400-3 E84AZESM2234LD 14
i550-C22/400-3 I0FAE322F100D0000S 18.5
i550-C30/400-3 E84AZESM3034LD
590 x 250 x 105
23
E84AZESM3734LD 25i550-C37/400-3
I0FAE345F100D0000S 32i550-C45/400-3
i550-C55/400-3 I0FAE355F100D0000S
700 x 250 x 105
36
i550-C75/400-3 I0FAE375F100D0000S 41.5
i550-C90/400-3
I0FAE411F100D0000S 855 x 250 x 130 63
i550-C110/400-3
From 22 kW, long distance mains lters are used. Mains lters are a combinaon of mains
choke and RFI lter.
Sine lter
Inverter Sine lters
Switching frequency Order code Rated inductance Max. output frequency
kHz mH Hz
i550-C0.37/400-3
4
8
EZS3-004A200 11.0
150
i550-C0.55/400-3
i550-C0.75/400-3
i550-C1.1/400-3
i550-C1.5/400-3
EZS3-010A200 5.10i550-C2.2/400-3
i550-C3.0/400-3
i550-C4.0/400-3
EZS3-017A200 3.07
i550-C5.5/400-3
i550-C7.5/400-3 EZS3-024A200 2.50
i550-C11/400-3 EZS3-032A200 2.00
i550-C15/400-3 EZS3-037A200 1.70
i550-C18/400-3 EZS3-048A200 1.20
i550-C22/400-3 EZS3-048A200 1.20
i550-C30/400-3 EZS3-061A200 1.00
i550-C37/400-3 EZS3-090A200 0.8
i550-C45/400-3 EZS3-090A200 0.8
i550-C55/400-3
2
4
EZS3-115A200 0.7
i550-C75/400-3 EZS3-150A200 0.5
Technical data
3-phase mains connecon 400 V
Sine lter
136
