Rated data
The output currents apply to these operang condions:
•
At a switching frequency of 2 kHz or 4 kHz: Max. ambient temperature 45°C.
•
At a switching frequency of 8 kHz or 16 kHz: Max. ambient temperature 40 °C.
Inverter i550-C0.25/230-1 i550-C0.25/230-2 i550-C0.37/230-1 i550-C0.37/230-2
Rated power kW P
N
0.25 0.25 0.37 0.37
Rated power hp P
N
0.33 0.33 0.5 0.5
Mains voltage range 1/PE AC 170 V ... 264 V, 45 Hz ... 65 Hz
Output voltage 3 AC 0-230/240 V
Rated mains current
without mains choke A I
r, AC
4 4 5.7 5.7
with mains choke A I
r, AC
3.6 3.6 4.8 4.8
Apparent output power kVA A
ON
0.6 0.6 0.9 0.9
Rated output current
2 kHz A I
OUT
- - - -
4 kHz A I
OUT
1.7 1.7 2.4 2.4
8 kHz A I
OUT
1.7 1.7 2.4 2.4
16 kHz A I
OUT
1.1 1.1 1.6 1.6
Power loss
2 kHz W - - - -
4 kHz W 15 15 18 18
8 kHz W 15 15 20 20
16 kHz W 19 19 24 24
at inverter disablecontroller
inhibit
W 6 6 6 6
Overcurrent cycle 180 s
Max. output current A I
max, out
2.6 2.6 3.6 3.6
Overload me s t
ol
60 60 60 60
Recovery me s t
re
120 120 120 120
Max. output current during the
recovery me
A 1.3 1.3 1.8 1.8
Overcurrent cycle 15 s
Max. output current A I
max, out
3.4 3.4 4.8 4.8
Overload me s t
ol
3 3 3 3
Recovery me s t
re
12 12 12 12
Max. output current during the
recovery me
A 1.3 1.3 1.8 1.8
Cyclic mains switching 3 mes per minute
Brake chopper
Max. output current A I
max, 1
2.2 2.2 2.2 2.2
Min. brake resistance Ω R
min
180 180 180 180
Max. motor cable length shielded
without EMC category m 50 50 50 50
Category C1 (2 kHz, 4 kHz, 8
kHz)
m 3 - 3 -
Category C2 (2 kHz, 4 kHz, 8
kHz)
m 15 - 15 -
Category C3 (2 kHz, 4 kHz, 8
kHz)
m 15 - 15 -
Weight kg 0.8 0.8 0.8 0.8
Weight lb 1.8 1.8 1.8 1.8
Technical data
1-phase mains connecon 230/240 V
Rated data
83
