Lenze i550 Series Project Planning Manual

Motor connecon
Inverter i550-C5.5/230-3
Connecon X105
Connecon type Screw terminal
Max. cable cross-secon mm² 6
Max. cable cross-secon AWG 8
Stripping length mm 9
Stripping length inch 0.35
Tightening torque Nm 0.5
Tightening torque lb-in 4.4
Required tool 0.6 x 3.5
The terminal data for the terminal X1 can be found under:4Terminal data ^ 72
Brake resistors
Inverter Brake resistor
Order code Rated resistance Rated power Thermal capacity Dimensions (h x b x
t)
Weight
Ω W kWs mm kg
i550-C0.25/230-2
ERBM180R050W 180 50 7.5 175 x 21 x 40 0.28
i550-C0.37/230-2
i550-C0.55/230-2
ERBM100R100W 100 100 15 240 x 80 x 95 0.37
i550-C0.75/230-2
i550-C1.1/230-2
ERBP033R200W
33
200 30 240 x 41 x 122 1
ERBP033R300W 300 45 320 x 41 x 122 1.4
i550-C1.5/230-2 ERBP033R200W 200 30 240 x 41 x 122 1
ERBP033R300W 300 45 320 x 41 x 122 1.4
i550-C2.2/230-2
ERBP033R200W
200 30
240 x 41 x 122
1
i550-C4.0/230-3
ERBP027R200W
27
320 x 41 x 122
ERBS027R600W 600 90 550 x 110 x 105 3.1
ERBS015R800W
15
800 120 710 x 110 x 105 3.9
ERBS015R01K2 1200 180 1020 x 110 x 105 5.6
ERBP018R300W 18 300 45
320 x 41 x 122
1.4
i550-C5.5/230-3
ERBP027R200W
27
200 30 1
ERBS027R600W 600 90 550 x 110 x 105 3.1
ERBS015R800W
15
800 120 710 x 110 x 105 3.9
ERBS015R01K2 1200 180 1020 x 110 x 105 5.6
ERBP018R300W 18 300 45 320 x 41 x 122 1.4
Mains chokes
Inverter Mains choke
Order code Number of phases Output current Inductance Dimensions (h x b x
t)
Weight
A mH mm kg
i550-C0.25/230-2 EZAELN3002B153
3
2 14.7 56 x 77 x 100 0.53
i550-C0.37/230-2
EZAELN3004B742 4 7.35 60 x 95 x 115 1.31
i550-C0.55/230-2
i550-C0.75/230-2
EZAELN3006B492 6 4.9 69 x 95 x 120 1.45
i550-C1.1/230-2
i550-C1.5/230-2 EZAELN3008B372 8 3.68
85 x 120 x 140
1.9
i550-C2.2/230-2 EZAELN3010B292 10 2.94 2
i550-C4.0/230-3 EZAELN3016B182 16 1.84 95 x 120 x 140 2.7
i550-C5.5/230-3 EZAELN3025B122 25 1.18 110 x 155 x 170 5.8
Technical data
3-phase mains connecon 230/240 V
Mains chokes
110

Lenze i550 Series Specifications

General

Protection Class	IP20
Ambient Temperature	-10°C to +50°C
Overload Capacity	150% for 60 seconds
Control Type	Vector control
Communication Interfaces	CANopen, Modbus, Ethernet, PROFIBUS, PROFINET
Safety	STO (Safe Torque Off)
Frequency Range	0 Hz
Cooling Method	Air cooling
Storage Temperature Range	-25°C to +70°C
Input Voltage Range	3-phase 380...480 V AC -15%/+10%
