Lenze i550 Series Project Planning Manual

Terminal data
Mains connecon
Inverter i550-C0.25/230-1 i550-C0.25/230-2 i550-C0.37/230-1 i550-C0.37/230-2
Connecon X100
Connecon type pluggable screw terminal
Max. cable cross-secon mm² 2.5 2.5 2.5 2.5
Max. cable cross-secon AWG 12 12 12 12
Stripping length mm 8 8 8 8
Stripping length inch 0.32 0.32 0.32 0.32
Tightening torque Nm 0.5 0.5 0.5 0.5
Tightening torque lb-in 4.4 4.4 4.4 4.4
Required tool 0.5 x 3.0
Mains connecon
Inverter i550-C0.55/230-1 i550-C0.55/230-2 i550-C0.75/230-1 i550-C0.75/230-2
Connecon X100
Connecon type pluggable screw terminal
Max. cable cross-secon mm² 2.5 2.5 2.5 2.5
Max. cable cross-secon AWG 12 12 12 12
Stripping length mm 8 8 8 8
Stripping length inch 0.32 0.32 0.32 0.32
Tightening torque Nm 0.5 0.5 0.5 0.5
Tightening torque lb-in 4.4 4.4 4.4 4.4
Required tool 0.5 x 3.0
Mains connecon
Inverter i550-C1.1/230-1 i550-C1.1/230-2 i550-C1.5/230-1 i550-C1.5/230-2
Connecon X100
Connecon type pluggable screw terminal
Max. cable cross-secon mm² 6 6 6 6
Max. cable cross-secon AWG 10 10 10 10
Stripping length mm 8 8 8 8
Stripping length inch 0.32 0.32 0.32 0.32
Tightening torque Nm 0.7 0.7 0.7 0.7
Tightening torque lb-in 6.2 6.2 6.2 6.2
Required tool 0.6 x 3.5
Mains connecon
Inverter i550-C2.2/230-1 i550-C2.2/230-2
Connecon X100
Connecon type pluggable screw terminal
Max. cable cross-secon mm² 6 6
Max. cable cross-secon AWG 10 10
Stripping length mm 8 8
Stripping length inch 0.32 0.32
Tightening torque Nm 0.7 0.7
Tightening torque lb-in 6.2 6.2
Required tool 0.6 x 3.5
Technical data
1-phase mains connecon 230/240 V
Terminal data
93

Lenze i550 Series Specifications

General

Protection Class	IP20
Ambient Temperature	-10°C to +50°C
Overload Capacity	150% for 60 seconds
Control Type	Vector control
Communication Interfaces	CANopen, Modbus, Ethernet, PROFIBUS, PROFINET
Safety	STO (Safe Torque Off)
Frequency Range	0 Hz
Cooling Method	Air cooling
Storage Temperature Range	-25°C to +70°C
Input Voltage Range	3-phase 380...480 V AC -15%/+10%
