Mounng
Shield mounng kit
Motor cable
If the shielding of the motor cable is centrally connected to an earthing bus in the control cab-
inet, no shielding is required.
For a direct connecon of the shielding of the motor cable to the inverter, the oponally avail-
able accessories can be used consisng of shield sheet and xing clips or wire clamps.
From 15 kW, the shield sheet is integrated.
Inverter Shield mounng kit
Order code VPE
Piece
i550-C0.25/230-1
EZAMBHXM014/M
5x motor shield sheet
10x xing clip
i550-C0.25/230-2
i550-C0.37/230-1
i550-C0.37/230-2
i550-C0.55/230-1
i550-C0.55/230-2
i550-C0.75/230-1
i550-C0.75/230-2
i550-C1.1/230-1
550-C1.1/230-2
i550-C1.5/230-1
i550-C1.5/230-2
i550-C2.2/230-1
i550-C2.2/230-2
i550-C0.37/400-3
i550-C0.55/400-3
i550-C0.75/400-3
i550-C1.1/400-3
i550-C1.5/400-3
i550-C2.2/400-3
i550-C3.0/400-3
EZAMBHXM015/M
5x motor shield sheet
5x xing clip
5x wire clamp (cable diameter 4 ... 15 mm)
i550-C4.0/400-3
i550-C5.5/400-3
i550-C7.5/400-3
EZAMBHXM016/M
5x motor shield sheet
5x xing clip
5x wire clamp (cable diameter 10 ... 20 mm)
i550-C11/400-3
i550-C15/400-3
i550-C18.5/400-3
i550-C22/400-3 EZAMBHXM004/M 5x wire clamp (cable diameter 15 ... 28 mm)
i550-C30/400-3 EZAMBHXM005/M 5x wire clamp (cable diameter 20 ... 37 mm)
i550-C37/400-3
i550-C45/400-3
i550-C55/400-3 EZAMBHXM005/M 5x wire clamp (cable diameter 20 ... 37 mm)
i550-C75/400-3
Accessories
Mounng
Shield mounng kit
249

Lenze i550 Series Specifications

General

Protection Class	IP20
Ambient Temperature	-10°C to +50°C
Overload Capacity	150% for 60 seconds
Control Type	Vector control
Communication Interfaces	CANopen, Modbus, Ethernet, PROFIBUS, PROFINET
Safety	STO (Safe Torque Off)
Frequency Range	0 Hz
Cooling Method	Air cooling
Storage Temperature Range	-25°C to +70°C
Input Voltage Range	3-phase 380...480 V AC -15%/+10%
