Lenze i550 Series Project Planning Manual

1-phase mains connecon 230/240 V
The connecon plan is valid for the inverters i550-Cxxx/230-1.
X287
X286
POWERLINK
X277
X276
Modbus TCP
X267 X266
EtherNet/IP
OUT
X257
IN
X256
PROFINET
OUT
X247
IN
X246
EtherCAT
X226
PROFIBUS
TB
COM
TA
X216
Modbus RTU
CL
CG
CH
X216
CANopen
Safety STO
X1
SIA
GS
SIB
DC SELV PELV 24 V /
(+19.2 … +28.8 V)
"
1k ... 10k
0 ... 10 V
S1
DI3 DI4
100 mA
4.4k
+24 V +10 V
4.4k 4.4k 4.4k
4.4k
10 mA
Standard I/O
GND
1 DO
1 DI 2 DI 3 DI 4 DI 5 DI
24E
GND
1 AI
2 AI
10V
GND
1 AO
24V
24E
X3
24V
4.4k
7 DI
4.4k
2 AO
1 DI
2 DO
GND
GND
6 DI
Application I/O
X105
U
V
W
Rb1
Rb2
+
X109
T1 T2
""
M
3~
+
J
J
NC
NO
COM
X9
AC 240 V
3 A
F1
…
F3
Q1
X100
L1
L2/N
2/ PE
170 V ... 264 VAC
45 Hz ... 65 Hz
+
2/ PE
170 V ... 264 VAC
45 Hz ... 65 Hz
+
F1
…
F2
Q1
X100
L1
L2/N
X100
L1
L2/N
F1
Q1
PE
N
L2
L1
2/N/ PE
208 V ... 240 VAC
PE
N
L3
L2
L1
3/N/ PE
208 V ... 240 VAC
PE
N
L3
L2
L1
+
1/N/PE
170 V ... 264 VAC
45 Hz ... 65 Hz
3/N/ PE
400 VAC
Fig. 4: Wiring example
S1 Start/Stop
Fx Fuses
Q1 Mains contactor
--- Dashed line = opons
Informaon on electrical installaon
Mains connecon
1-phase mains connecon 230/240 V
51

Lenze i550 Series Specifications

General

Protection Class	IP20
Ambient Temperature	-10°C to +50°C
Overload Capacity	150% for 60 seconds
Control Type	Vector control
Communication Interfaces	CANopen, Modbus, Ethernet, PROFIBUS, PROFINET
Safety	STO (Safe Torque Off)
Frequency Range	0 Hz
Cooling Method	Air cooling
Storage Temperature Range	-25°C to +70°C
Input Voltage Range	3-phase 380...480 V AC -15%/+10%
