Lenze i550 Series Project Planning Manual

Mains chokes
Inverter Mains choke
Order code Number of phases Output current Inductance Dimensions (h x b x
t)
Weight
A mH mm kg
i550-C3.0/400-3 EZAELN3008B372
3
8 3.68
85 x 120 x 140
1.9
i550-C4.0/400-3 EZAELN3010B292 10 2.94 2
i550-C5.5/400-3 EZAELN3016B182 16 1.84 95 x 120 x 140 2.7
i550-C7.5/400-3 EZAELN3020B152 20 1.47 95 x 155 x 165 3.8
i550-C11/400-3 EZAELN3025B122 25 1.18
110 x 155 x 170
5.8
i550-C15/400-3 EZAELN3030B981 30 0.98 5.85
i550-C18/400-3 EZAELN3040B741 40 0.74 112 x 185 x 200 6.8
i550-C22/400-3 EZAELN3050B591 50 0.59 112 x 185 x 210 8.35
i550-C30/400-3 EZAELN3063B471 63 0.47 122 x 185 x 210 9.65
i550-C37/400-3 EZAELN3080B371 80 0.37 125 x 210 x 240 12.5
i550-C45/400-3 EZAELN3090B331 90 0.33 115 x 267 x 205 11.5
i550-C55/400-3 EZAELN3125B241 125 0.24 139 x 291 x 215 17.5
i550-C75/400-3 EZAELN3160B191 160 0.19 149 x 291 x 215 22.5
i550-C90/400-3 EZAELN3180B171 180 0.17 164 x 316 x 235 26
i550-C110/400-3 EZAELN3200B151 200 0.15 144 x 352 x 265 25
Technical data
3-phase mains connecon 480 V "Light Duty"
Mains chokes
198

Lenze i550 Series Specifications

General

Protection Class	IP20
Ambient Temperature	-10°C to +50°C
Overload Capacity	150% for 60 seconds
Control Type	Vector control
Communication Interfaces	CANopen, Modbus, Ethernet, PROFIBUS, PROFINET
Safety	STO (Safe Torque Off)
Frequency Range	0 Hz
Cooling Method	Air cooling
Storage Temperature Range	-25°C to +70°C
Input Voltage Range	3-phase 380...480 V AC -15%/+10%
