Lenze i550 Series Project Planning Manual

Topologies / network
The inverters can be equipped with dierent eldbus networks.
The topologies and protocols typical for the prevailing networks are supported.
Currently available networks:
CANopen® is a communicaon protocol based on CAN.
CANopen® is a registered community trademark of the CAN user organisaon CiA® (CAN in Automaon e. V.).
Device descripons for the download: EDS les for Lenze devices
The Modbus protocol is an open communicaon protocol based on a client/server architecture and developed for
the communicaon with programmable logic controllers.
The further development is carried out by the internaonal user organisaon Modbus Organizaon, USA.
PROFIBUS® (Process Field Bus) is a widely-used eldbus system for the automaon of machines and producon
plants.
PROFIBUS® is a registered trademark and patented technology licensed by the PROFIBUS & PROFINET Internaonal
(PI) user organisaon.
Device descripons for the download: GSD les for Lenze devices
Safety over EtherCAT® is a registered trademark and patented technology, licensed by Beckho Automaon GmbH,
Germany.
EtherCAT® (Ethernet for Controller and Automaon Technology) is an Ethernet-based eldbus system which fulls
the applicaon prole for industrial realme systems
EtherCAT® is a registered trademark and patented technology, licensed by Beckho Automaon GmbH, Germany.
Device descripons for the download: XML/ESI les for Lenze devices
EtherNet/IP™ (EtherNet Industrial Protocol) is a eldbus system based on Ethernet which uses the Common Indus-
trial Protocol™ (CIP™) for data exchange.
EtherNet/IP™ and Common Industrial Protocol™ (CIP™) are trademarks and patented technologies, licensed by the
user organisaon ODVA (Open DeviceNet Vendor Associaon), USA.
Device descripons for the download: EDS les for Lenze devices
PROFINET® (Process Field Network) is a real-me capable eldbus system based on Ethernet.
PROFINET® is a registered trademark and patented technology licensed by the PROFIBUS & PROFINET Internaonal
(PI) user organisaon.
Device descripons for the download: GSDML les for Lenze devices
The cered safety protocol for the transfer of safety-related data via PROFINET®.
Ethernet POWERLINK is and Ethernet-based eldbus system which fulls the applicaon prole for industrial real-
me systems.
POWERLINK is an open technology.
Detailed informaon on POWERLINK can be found on the web page of the Ethernet POWERLINK Standardizaon
Group (EPSG): hp://www.ethernet-powerlink.org
More informaon on the supported networks can be found at:
hp://www.lenze.com
Product informaon
The modular system
Topologies / network
21

Lenze i550 Series Specifications

General

Protection Class	IP20
Ambient Temperature	-10°C to +50°C
Overload Capacity	150% for 60 seconds
Control Type	Vector control
Communication Interfaces	CANopen, Modbus, Ethernet, PROFIBUS, PROFINET
Safety	STO (Safe Torque Off)
Frequency Range	0 Hz
Cooling Method	Air cooling
Storage Temperature Range	-25°C to +70°C
Input Voltage Range	3-phase 380...480 V AC -15%/+10%
