Rated data
The output currents apply to these operang condions:
•
At a switching frequency of 2 kHz or 4 kHz: Max. ambient temperature 45°C.
•
At a switching frequency of 8 kHz or 16 kHz: Max. ambient temperature 40 °C.
Inverter i550-C0.25/120-1 i550-C0.37/120-1 i550-C0.75/120-1 i550-C1.1/120-1
Rated power kW P
N
0.25 0.37 0.75 1.1
Rated power hp P
N
0.33 0.5 1 1.5
Mains voltage range 1/PE AC 90 V ... 132 V, 45 Hz ... 65 Hz
Output voltage 3 AC 0-230/240 V
Rated mains current
without mains choke A I
r, AC
6.8 9.6 16.8 22.9
with mains choke A I
r, AC
6 8.5 14.7 17.1
Apparent output power kVA A
ON
0.6 0.9 1.6 2.2
Rated output current
2 kHz A I
OUT
1.7 2.4 4.2 6
4 kHz A I
OUT
1.7 2.4 4.2 6
8 kHz A I
OUT
1.7 2.4 4.2 6
16 kHz A I
OUT
1.1 1.6 2.8 4
Power loss
2 kHz W 15 19 29 39
4 kHz W 16 21 29 40
8 kHz W 18 23 35 47
16 kHz W 20 24 36 45
at inverter disablecontroller
inhibit
W 6 6 6 6
Overcurrent cycle 180 s
Max. output current A I
max, out
2.6 3.6 6.3 9
Overload me s t
ol
60 60 60 60
Recovery me s t
re
120 120 120 120
Max. output current during the
recovery me
A 1.3 1.8 3.2 4.5
Overcurrent cycle 15 s
Max. output current A I
max, out
3.4 4.8 8.4 12
Overload me s t
ol
3 3 3 3
Recovery me s t
re
12 12 12 12
Max. output current during the
recovery me
A 1.3 1.8 3.2 4.5
Cyclic mains switching 3 mes per minute
Brake chopper
Max. output current A I
max, 1
2.2 2.2 8.3 8.3
Min. brake resistance Ω R
min
180 180 47 47
Max. motor cable length shielded
without EMC category m 50 50 50 50
Category C1 (2 kHz, 4 kHz, 8
kHz)
m - - - -
Category C2 (2 kHz, 4 kHz, 8
kHz)
m - - - -
Category C3 (2 kHz, 4 kHz, 8
kHz)
m - - - -
Weight kg 1 1 1.35 1.35
Weight lb 2.2 2.2 3 3
Technical data
1-phase mains connecon 120 V
Rated data
77
