Lenze i550 Series Project Planning Manual

EMC-compliant installaon
Structure of a CE-typical drive system
The drive system (frequency inverter and drive) corresponds to 2014/30/EU: EMC Direcve if
it is installed according to the specicaons of the CE-typical drive system.
The structure in the control cabinet must support the EMC-compliant installaon with shiel-
ded cables.
•
Please use highly conducve shield connecons.
•
Connect the housing with shielding eect to the grounded mounng plate with a surface
as large as possible, e. g. of inverters and RFI lters.
•
Use central earthing points.
Matching accessories makes eecve shielding easier.
•
Shield sheets
•
Shield clips/shield clamps
•
Metallic cable es
Mains connecon, DC supply
•
Inverters, mains chokes, or mains lters may only be connected to the mains via unshiel-
ded single cores or unshielded cables.
•
When a line lter is used, shield the cable between mains lter or RFI lter and inverter if
its length exceeds 300 mm. Unshielded cores must be twisted.
•
In DC-bus operaon or DC supply, use shielded cables.
-
Only certain inverters are provided with this connecon facility.
Rated mains voltage DC voltage range
V
400
DC 450 V - 0 % ... 750 V + 0 %
480
Informaon on project planning
Control cabinet structure
EMC-compliant installaon
41

Lenze i550 Series Specifications

General

Protection Class	IP20
Ambient Temperature	-10°C to +50°C
Overload Capacity	150% for 60 seconds
Control Type	Vector control
Communication Interfaces	CANopen, Modbus, Ethernet, PROFIBUS, PROFINET
Safety	STO (Safe Torque Off)
Frequency Range	0 Hz
Cooling Method	Air cooling
Storage Temperature Range	-25°C to +70°C
Input Voltage Range	3-phase 380...480 V AC -15%/+10%
