Lenze i550 Series Project Planning Manual

Brake resistors
Inverter Brake resistor
Order code Rated resistance Rated power Thermal capacity Dimensions (h x b x
t)
Weight
Ω W kWs mm kg
i550-C3.0/400-3
ERBP082R200W
82
200 30 320 x 41 x 122 1
ERBS082R780W 780 117 666 x 124 x 122 3.6
i550-C4.0/400-3
ERBP047R200W
47
200 30 320 x 41 x 122 1
ERBS047R400W 400 60 400 x 110 x 105 2.3
ERBS047R800W 800 120 710 x 110 x 105 4
i550-C5.5/400-3
ERBP047R200W 200 30 320 x 41 x 122 1
ERBS047R400W 400 60 400 x 110 x 105 2.3
ERBS047R800W 800 120 710 x 110 x 105 4
i550-C7.5/400-3
ERBP027R200W
27
200 30 320 x 41 x 122 1
ERBS027R600W 600 90 550 x 110 x 105 3.1
ERBS027R01K2 1200 180 1020 x 110 x 105 5.6
i550-C11/400-3
ERBP027R200W 200 30 320 x 41 x 122 1
ERBS027R600W 600 90 550 x 110 x 105 3.1
ERBS027R01K2 1200 180 1020 x 110 x 105 5.6
i550-C15/400-3
ERBS018R800W
18
800 120 710 x 110 x 105 3.9
ERBS018R01K4 1400 210 1110 x 110 x 105 6.2
ERBS018R02K8 2800 420 1110 x 200 x 105 12
ERBG018R04K3 4300 645 486 x 426 x 302 13.5
ERBP018R300W 300 45 320 x 41 x 122 1.4
i550-C18/400-3
ERBS015R800W
15
800 120 710 x 110 x 105 3.9
ERBS015R01K2 1200 180 1020 x 110 x 105 5.6
ERBS015R02K4 2400 420 1020 x 200 x 105 10
ERBG015R06K2 6200 930 486 x 526 x 302 17
ERBG015R03K3 3300 495 486 x 326 x 302 12.6
i550-C22/400-3
ERBS015R800W 800 120 710 x 110 x 105 3.9
ERBS015R01K2 1200 180 1020 x 110 x 105 5.6
ERBS015R02K4 2400 420 1020 x 200 x 105 10
ERBG015R06K2 6200 930 486 x 526 x 302 17
ERBG015R03K3 3300 495 486 x 326 x 302 12.6
i550-C30/400-3
ERBG075D01K9 7.5 1900 285 486 x 236 x 302 9.5i550-C37/400-3
i550-C45/400-3
i550-C55/400-3
ERBG005R02K6 5 2600 390 486 x 326 x 302 11
i550-C75/400-3
i550-C90/400-3
ERBG028D04K1 2.8 4100 615 486 x 426 x 302 12.8
i550-C110/400-3
Technical data
3-phase mains connecon 400 V "Light Duty"
Brake resistors
152

Lenze i550 Series Specifications

General

Protection Class	IP20
Ambient Temperature	-10°C to +50°C
Overload Capacity	150% for 60 seconds
Control Type	Vector control
Communication Interfaces	CANopen, Modbus, Ethernet, PROFIBUS, PROFINET
Safety	STO (Safe Torque Off)
Frequency Range	0 Hz
Cooling Method	Air cooling
Storage Temperature Range	-25°C to +70°C
Input Voltage Range	3-phase 380...480 V AC -15%/+10%
