Lenze i550 Series Project Planning Manual

Shield mounng of the control cables
In case of the control unit, the shield sheet for control cables is integrated.
Usually, the shields can be xed with standard plasc cable es.
Oponally, xing clips are suitable for the shield connecons of the control cables of inver-
ters 0.25 kW ... 0.75 kW.
Shield mounng kit
Order code VPE
Piece
EZAMBHXM007/M 20x xing clip
Terminal strips
For connecng the inverter, the connecons are equipped with pluggable terminal strips.
Pluggable terminal strips are available separately for service purposes or if cable harnesses
need to be physically separated.
Inverter Terminal strips
Mains connecon X100
Terminal strips
Motor connecon X105
Order code VPE Order code VPE
Piece Piece
i550-C0.25/230-1
EZAEVE032/M
10
EZAEVE039/M 5
i550-C0.37/230-1
i550-C0.55/230-1
i550-C0.75/230-1
i550-C1.1/230-1
EZAEVE033/Mi550-C1.5/230-1
i550-C2.2/230-1
i550-C0.25/230-2
EZAEVE034/M
10
i550-C0.37/230-2
i550-C0.55/230-2
i550-C0.75/230-2
i550-C1.1/230-2
EZAEVE035/Mi550-C1.5/230-2
i550-C2.2/230-2
i550-C0.37/400-3
EZAEVE037/M 5
i550-C0.55/400-3
i550-C0.75/400-3
i550-C1.1/400-3
i550-C1.5/400-3
i550-C2.2/400-3
Terminal strips Order code VPE Terminal strips Order code VPE
Piece Piece
Safety (STO) X1 EZAEVE029/M 10 Standard I/O X3 EZAEVE040/M 5
Relay X9 EZAEVE030/M 10 Applicaon-I/O X3 EZAEVE041/M 5
Motor PTC X109 EZAEVE031/M 10 CANopen / Modbus X216 EZAEVE042/M 10
Accessories
Mounng
Terminal strips
250

Lenze i550 Series Specifications

General

Protection Class	IP20
Ambient Temperature	-10°C to +50°C
Overload Capacity	150% for 60 seconds
Control Type	Vector control
Communication Interfaces	CANopen, Modbus, Ethernet, PROFIBUS, PROFINET
Safety	STO (Safe Torque Off)
Frequency Range	0 Hz
Cooling Method	Air cooling
Storage Temperature Range	-25°C to +70°C
Input Voltage Range	3-phase 380...480 V AC -15%/+10%
