8400 BaseLine D | Software Manual Drive Application Overview of the software structure of the drive application function | Functions of the drive application 138 L Firmware 03.00 - DMS EN 5.0 - 07/2009
8.1.2 Functions of the drive application "Actuating drive - speed"
Function BaseLine D BaseLine C StateLine C HighLine C
Connection of device I/Os Adjustable via parameter tables
Additionally configurable via parameters or FB Editor
Signal flow generation Predefined in the device
Some functions can be switched on and off via parameters
Freely configurable
via FB Editor
FB Editor, I/O level - Yes, editable
FB Editor, application level Diagnostics only Yes, editable
Open-loop operation
Closed-loop operation
Yes
No
Yes
No
Yes
Yes
Yes
Yes
Speed setpoint selection via ramp function
generator with S-shaped (jerk-free) ramp
characteristic
Yes Yes Yes Yes
Number of fixed setpoints 3 3 15 15
Number of ramp times 1 1 15 15
Function for comparing the actual speed
with the digital feedback
Yes Yes Yes Yes
Reversal of CW/CCW rotation via digital
signal
Yes Yes Yes Yes
Set/reset error Yes Yes Yes Yes
Diagnostics of the digital and analog inputs
and outputs
Yes Yes Yes Yes
Configurable connection of control and
status signals
Yes Yes Yes Yes
Adjustable load monitoring Yes Yes No Yes
Integrated automatic brake operation Yes, simple speed
threshold
Yes, simple speed
threshold
Yes, simple speed
threshold
Yes, with additional
functions
Expandable by signal interconnection Only in the I/O level Only in the I/O level Only in the I/O level Yes
Blocking speeds Yes Yes Yes Yes
Motor potentiometer function Yes Yes Yes Yes
PID process controller Yes Yes Yes Yes
Manual jog No No Yes Yes, two speeds
Automatic load identification and control
parameter setting
No No No No
