8400 BaseLine D | Software Manual
Motor control (MCTRL)
Selection of the operating mode
5.1.2 Vector control
 Tip!
The complete structure of the vector control is shown in the Signal flow
( 105) .
 Stop!
• The connected motor may be maximum one power class lower than the
motor assigned to the controller.
• The operation with vector control is only permissible for a single drive.
• The operation with sensorless vector control (SLVC) is not
permissible for
hoists.
• A stable operation is only possible if one of the following three entries are
made:
– Enter the nameplate data and equivalent circuit data of the motor (motor
leakage inductance and mutual motor inductance, slip compensation and
stator and rotor resistance) manually or
– enter the selected motor via the Lenze motor catalogue or
– enter the motor nameplate data and carry out the motor parameter
identification.
• When you enter the motor nameplate data, take into account the phase
connection implemented for the motor (star or delta connection). Only enter
the data applying to the selected connection type.
