8400 BaseLine D | Software Manual
Function library
Function blocks
148 L Firmware 03.00 - DMS EN 5.0 - 07/2009
9.1.1.2 JOG setpoints
JOG setpoints are constant values which are stored in the memory under C39/1 ... C39/3.
 The JOG setpoints can be called binary-coded using the bJog1 ... bJog2 selection inputs
so that 3 options are available.
 The main setpoint nNSet_a must be freely defined for bJog1 ... bJog2 = FALSE.
 The number of selection inputs to be assigned depends on the number of JOG setpoints
required.
9.1.1.3 Setpoint inversion
The output signal of the JOG function is led via an inverter.
The sign of the setpoint changes if bNSetInv is set to TRUE.
Used
Main setpoint
bJog2 bJog1
FALSE FALSE nNSet_a
FALSE True C39/1
True FALSE C39/2
True True C39/3
