Firmware 03.00 - DMS EN 5.0 - 07/2009 L 167
8400 BaseLine D | Software Manual
Parameter reference
10 Parameter reference
All parameters for controller parameter setting and monitoring are called "codes".
The codes are numbered and indicated by the prefix "C" before the code, e.g. "C00002".
For the sake of clarity, some codes contain "subcodes" for saving parameters. This
Manual uses a slash "/" as a separator between code and subcode, e.g. C00118/3".
The terms "code" and "subcode" generally correspond to the terms "index" and
"subindex" and "parameter" and "subparameter".
In case of the 8400 frequency inverter, the following functions can be carried out via
codes:
– Setting of setpoints, e.g. acceleration time.
– Display of actual values, e.g. actual motor current.
– Configuration of signal links, e.g. assignment of the digital input terminals to control
inputs of the technology application.
– Configuration of monitoring functions, e.g. selection of the error response and
setting of trigger thresholds.
Parameters which are only available in the controller from a certain software version
onwards, are marked with a corresponding note in the parameter description ("from
version xx.xx.xx").
The parameter descriptions are based on the software version V03.00.00
Tip!
For quick reference of a parameter with a certain name, simply use the index of the
online documentation. The index always contains the corresponding code in
parentheses after the name.
For general information on how to read and change parameters, please see the
online documentation for the »Engineer«.
