Lenze L-force 8400 BaseLine D User Manual

Firmware 03.00 - DMS EN 5.0 - 07/2009 L 69
8400 BaseLine D | Software Manual
Drive control (DCTRL)
Activate/deactivate quick stop function (QSP)
4.5 Activate/deactivate quick stop function (QSP)
When the quick stop function is activated, it
 disconnects the motor control from the selected setpoint and brakes the motor to
standstill (n
act
= 0) along the quick stop ramp (C105).
 sets the pulse inhibit (CINH) if the function auto DCB has been activated via C019
.
Activation of the quick stop function
The quick stop function can be activated by different signal sources:
 Device command C002/17
, activate quick stop
 Input signal at the LS_MotorInterface
system block (motor control) set to TRUE.
 Tip!
The cause of a quick stop can be displayed via the parameter C159
.
