Firmware 03.00 - DMS EN 5.0 - 07/2009 L 25
8400 BaseLine D | Software Manual
Commissioning
Parameter setting and diagnosing directly at the controller
3.2.3 Messages
The current status of the controller is constituted via
ƒ six coloured LEDs, see Signalling of the LEDs "D" and "E"
( 24)
ƒ messages:
Message Meaning
PASS Password input
CAL blinking Identification is in progress. Operation is not enabled yet.
CAL / Stop alternatively blinking Identification is ready to start
CAL / Err alternatively blinking Identification is not ready to start. Either C088, or C089, or
C090 is 0.
bF blinking Identification error. Drive ID stored in EMP does not match
the drive ID stored in the controller.
CL constant CL: Clamp
Current limit set in C022 is reached.
FCL constant Fast current limit value (higher than value set in C022) is
reached
FSt constant Flying start is in progress
dec constant Deceleration is temporarily suspended because of higher bus
voltage
br flashes during the hold time of the
DC brake
DC brake is in progress
