8400 BaseLine D | Software Manual
Motor control (MCTRL)
Selection of the operating mode
90 L Firmware 03.00 - DMS EN 5.0 - 07/2009
5.1.3 Automatic motor parameter identification
The motor parameter identification serves to determine the motor data, the inverter
characteristic and the effects of the motor cable.
Overview of the relevant parameters
[5-2] Codes for automatic motor parameter identification
 Danger!
During the motor parameter identification, the motor is energised via the
outputs U, V and W of the controller!
Observe the corresponding safety instructions!
 Note!
We strongly recommend to execute the motor parameter identification prior to
the initial commissioning of the sensorless vector control.
Parameter Name INFO
C015
V/f base frequency Value measured during the parameter identification
or calculated value
C021
Slip compensation Value measured during the parameter identification
or calculated value
C081
Nameplate data
C084
Stator resistance Value measured during the parameter identification
or calculated value
C085
Leakage inductance Value measured during the parameter identification
or calculated value
C087
Rated motor speed Nameplate data
C088
Rated motor current Nameplate data
C089 Rated motor current Nameplate data
C090
Rated motor current Nameplate data
C091
Motor cos ϕ Nameplate data
C092 Stator inductance Value measured during the parameter identification
or calculated value
