8400 BaseLine D | Software Manual
Parameter reference
Structure of the parameter descriptions
168 L Firmware 03.00 - DMS EN 5.0 - 07/2009
10.1 Structure of the parameter descriptions
Each parameter is described in the Parameter list
in the form of a table which consists of
the following three areas:
Table header
The table header contains the following general information:
 Parameter number (Cxxxxx)
 Parameter name (display text in »Engineer» and keypad)
 Data type
 Parameter index in decimal and hexadecimal notation for access via a fieldbus, e.g.
system bus (CAN).
 Tip!
The parameter index is calculated as follows:
• Index [dec] = 24575 - code
• Index [hex] = 0x5FFF - code
Example for code C00005:
• Index [dec] = 24575 - 5 = 24570
• Index [hex] = 0x5FFF - 0x{5} = 0x5FFA
Table contents
The table contains further general explanations & notes on the parameter and the possible
settings the representation of which depends on the parameter type:
 Parameters with read-only access
 Parameters with write access
Table footer
The table footer contains the Parameter attributes
.
