8400 BaseLine D | Software Manual
Commissioning
Commissioning of the drive application with the »Engineer«
38 L Firmware 03.00 - DMS EN 5.0 - 07/2009
An overview of the inputs and outputs assigned as a function of the control source can be
found in a configuration table in the chapter Pre-assignment of the drive application
( 140).
The configuration table contains a selection for the most frequently used signals so that a
quick commissioning with only a few operator control action is possible. If the described
pre-assignment of the application block is not suitable for the drive task, select code C007
= "0" to implement an individual configuration by means of the FB editor.
This allows for easy commissioning of the application, e.g. together with the setpoint box
available in the Lenze accessories program.
3.4.6 Start program
RFR = TRUE: Enable controller
The setpoint potentiometer ("R", see graphics [3-4]
) serves to vary the speed.
