8400 BaseLine D | Software Manual
Motor control (MCTRL)
Motor selection
5.2.1 Manual parameter setting of external motors
External motor data can be entered manually if you have the equivalent circuit diagram
and nameplate data available.
 Tip!
For the improvement of the concentricity factor, we recommend to carry out the
motor parameter identification of the external motor first, and then enter the data
for the manual parameterisation.
Improving the concentricity factor includes
• the adjustment of the inverter error characteristic to the drive system and
• the knowledge of the motor cable resistance.
Both factors are determined during the motor parameter identification.
Overview of the relevant parameters
[5-5] Codes for the manual parameterisation of the motor data
Parameter INFO
C015
V/f base frequency
C021
Slip compensation
C081
Nameplate data, rated motor power
C084
Data of the equivalent circuit diagram of the motor
C085
Data of the equivalent circuit diagram of the motor
C087
Nameplate data, rated motor speed
C088
Nameplate data, rated motor current
C089
Nameplate data, rated motor frequency
C090
Nameplate data, rated motor voltage
C091
Nameplate data, motor cos ϕ
C092
Data of the equivalent circuit diagram of the motor
