Lenze L-force 8400 BaseLine D User Manual

Firmware 03.00 - DMS EN 5.0 - 07/2009 L 45
8400 BaseLine D | Software Manual
Drive control (DCTRL)
4 Drive control (DCTRL)
This chapter gives information about the device function "Drive control DCTRL". This device
function serves to control the controller into defined states and retrieve status information
via the system block LS_DriveInterface:
 The device displays status information in different ways
– as optical display via front LEDs to signalise the operating status,
see chapterDiagnostics
( 23).
– as text message in the Engineer.
– as process signal at the output of the system block LS_DriveInterface
– as diagnostic parameter
 The operating states of the controller are based on the DS402 standard. Device states
( 46)
