Lenze L-force 8400 BaseLine D User Manual

Firmware 03.00 - DMS EN 5.0 - 07/2009 L 219
8400 BaseLine D | Software Manual
Parameter reference
Table of attributes
. 10.3 Table of attributes
The table of attributes contains information required for a communication with the
controller via parameters.
How to read the table of attributes:
Column Meaning Entry
Code Parameter designation Cxxxxx
Name Parameter short text (display text) Text
Index dec Index under which the parameter is addressed.
The subindex for array variables corresponds to the
Lenze subcode number.
24575 - Lenze code Is only required for access via a bus sys-
tem.
hex 5FFF
h
- Lenze code number
Data DS Data structure E Single variable
(only one parameter element)
A Array variable
(several parameter elements)
DA Number of array elements (subcodes) Number
DT Data type BITFIELD_8 1 byte bit-coded
BITFIELD_16 2 byte bit-coded
BITFIELD_32 4 byte bit-coded
INTEGER_8 1 byte with sign
INTEGER_16 2 byte with sign
INTEGER_32 4 byte with sign
UNSIGNED_8 1 byte without sign
UNSIGNED_16 2 byte without sign
UNSIGNED_32 4 byte without sign
VISIBLE_STRING ASCII string
Factor Factor for data transmission via a bus system, de-
pending on the number of decimal positions
Factor 1 ≡ no decimal positions
10 ≡ 1 decimal position
100 ≡ 2 decimal positions
1000 ≡ 3 decimal positions
Access R Read access ; Reading permitted
W Write access ; Writing permitted
CINH Controller inhibit required ; Writing is only possible if controller inhibit is set
Code Name Index Data Access
dec hex DS DA DT Factor R W CINH
C00002
Controller commands 24573 5FFD A 32 UNSIGNED_8 1 ;;
C00003
Status of last device command 24572 5FFC E 1 UNSIGNED_8 1 ;
C00006
Select motor control 24569 5FF9 E 1 UNSIGNED_8 1 ;;
C00007
Select control mode 24568 5FF8 E 1 UNSIGNED_16 1 ;;
C00010
Minimum analog setpoint 24565 5FF5 A 1 INTEGER_16 100 ;;
C00011
Appl.: Reference speed 24564 5FF4 E 1 UNSIGNED_16 1 ;;
C00012
Accel. time - main setpoint 24563 5FF3 E 1 UNSIGNED_32 1000 ;;
C00013
Decel. time - main setpoint 24562 5FF2 E 1 UNSIGNED_32 1000 ;;
C00015
VFC: V/f base frequency 24560 5FF0 E 1 UNSIGNED_16 10 ;;
C00016
VFC: Vmin boost 24559 5FEF E 1 UNSIGNED_16 100 ;;
C00018
Switching frequency 24557 5FED E 1 UNSIGNED_8 1 ;;
C00019
Auto-DCB: Threshold 24556 5FEC E 1 UNSIGNED_16 1 ;;
C00021
Slip comp. 24554 5FEA E 1 INTEGER_16 100 ;;
C00022
Imax in motor mode 24553 5FE9 E 1 UNSIGNED_16 100 ;;
C00023
Imax in generator mode 24552 5FE8 E 1 INTEGER_16 100 ;;
C00024
Comparison value N_Act 24551 5FE7 E 1 INTEGER_16 100 ;;
C00026
AINx: Offset 24549 5FE5 A 1 INTEGER_16 100 ;;
