8400 BaseLine D | Software Manual
Commissioning
Parameter setting and diagnosing directly at the controller
3.2 Parameter setting and diagnosing directly at the controller
Parameter setting
The front of the controller is provided with control elements which serve to access the
parameters (also called codes) stored in the controller.
 An overview with a corresponding description of the codes can be found in chapter
Parameter reference
( 167).
 An overview of the menu structure of the internal keypad can be found in chapter
Menu structure
( 22).
Diagnosing
The optical display of the internal keypad shows important status information of the
controller by LEDs. The positions of the coloured LEDs are marked on the housing by letters.
 More information on diagnostics options and messages can be found in the chapters
Diagnostics
( 23)
Messages ( 25)
 The different controller states are described in chapter
Device states
( 46)
 Tip!
Extensive parameter settings and configurations should be carried out with the L-
force »Engineer«. If you want to use the L-force »Engineer«, the online help and the
software documentation for the controller will support you.
