MMX8x4-HT series – User's Manual 102
Set the Subnet Mask
Subnet mask can be set as follows.
Command and Response
<subnet_mask>}
<subnet_mask>
Parameters
See the section.
Example
INFO:
mask is not valid.
Set the Gateway Address
Gateway address can be set as follows.
Command and Response
<gateway_addr>}
<gateway_addr>
Parameters
See the section.
Example
INFO:
contains the static IP gateway address that is stored in the device even if DHCP is enabled. In that case,
the latest valid gateway address (for static IP) is stored.
Apply Network Settings
Apply the network settings and restart the network interface.
Command and Response
{ip_apply}
Example
{ip_apply}
GPIO Settings
DIFFERENCE: This command is available in MMX8x4-HT420M and MMX8x8-HDMI-4K-A-USB20 models.
Set GPIO State
GPIO state can be changed. #gpio
Command and Response
{GPIO<port_nr><direction>;<output_level>}
(GPIO<port_nr><direction>;<output_level>
Parameters
Parameter description Parameter values
<direction> Direction of the signal I: input
O: output
<output_level> Current level of the pin H: high
L: low
Example
INFO: The GPIO state can be queried by typing the {GPIO<port_nr> command.
Relay Settings
DIFFERENCE: These commands are available in MMX8x4-HT420M model.
Set Relay Connection State
Command and Response #relay
<port_nr><direction>;<state>}
<port_nr><direction>;<state>
Parameters
Parameter description Parameter values
<direction> Direction of the signal O: it is always O (output)
<state> Current state of the pin O: opened
C: closed
Example
INFO: <port_nr> command.
