MMX8x4-HT series – User's Manual 155
Hotplug Detect
This property indicates that the connected source or sink is connected.
Command and Response
ç <port>.Power5vIn
æ <port><power5v_status>
Parameters
<power05v_status> true:
false:
Example
ç
æ
INFO: Advanced analog audio output setting commands are available in MMX8x4-HT400MC and
MMX8x4-HT420M model.
It gives a feedback about the actual level of the microphone input signal.
For more details see Panorama or Balance Settings section.
Command and Response
ç <sign_level>
æ <sign_level><indicator_status>
Parameters
Parameter
description
Parameter values
<sign_level> Actual level of
the audio signal
IndicatorPeak: Peak level
IndicatorNominal: Nominal level
IndicatorSignal: Signal level
<indicator_status> Indicator status true: The audio signal reaches the <sign_level>
false: The audio signal does not reach the <sign_level>
Example
ç
æ
The microphone input signal above the peak value.
It gives a feedback about the actual level of the advanced analog input, embedded audio input and the
advanced audio output signal. For more details see Panorama or Balance Settings section.
Command and Response
ç <advanced_port>.<sign_level><ch>
æ <advanced_port>.<sign_level><ch><status>
Example
ç
æ
Parameters
Parameter
description
Parameter values
<advanced_port> Advanced
analog audio
port
I10: Advanced analog audio input
I11: Embedded audio input
O6: Advanced analog audio output
<sign_level> Actual level
of the audio
signal
IndicatorPeak: Peak level
IndicatorNominal: Nominal level
IndicatorSignal: Signal level
<ch> left: refers to the left channel
right: refers to the right channel
<status> Indicator
status
true: The audio signal reaches the <sign_level>
false: The audio signal does not reach the <sign_level>
