 MMX8x4-HT series – User's Manual 152

Powering on a Computer over Ethernet (Wake-on-LAN)
The well-known wake-on-lan feature (sending magic Packet to the target PC) is available by the following
command:
Command and Response
ç MAC_address)
æ 
Example
ç 
æ 
Please make sure the feature is enabled in the target PC and it is powered (but switched off).

Set Relay Connection Status
INFO:  This command is available in MMX8x4-HT420M model.
Command and Response #relay
ç <relay_port><relay_status>
æ <relay_port><relay_status>
Parameters
 Parameter description Parameter values
<relay_port> Relay port number P1-P4
<relay_staus> Relay port status O: Open
C: Close
Example
ç 
æ 
P1 relay port is set to be closed.
GPIO Port Settings
INFO:  This command is available in MMX8x4-HT420M model.
Set the Direction of a GPIO Pin
Command and Response #gpio
ç <gpio_port><dir>
æ <gpio_port><dir>
Parameters
<dir> I: input direction of the GPIO pin
O: output direction of the GPIO pin
Example
ç 
æ 




