Lightware MMX8x4-HT Series User Manual


12. Appendix MMX8x4-HT series – User's Manual 187



Port name
Video port nr.
(LW2)
Video port nr.
(LW3)
Emulated
EDID memory
Audio port nr.
(LW2)
Audio port nr.
(LW3)
TPS IN 1 01 I1 F47 - I1
TPS IN 2 02 I2 F47 - I2
TPS IN 3 03 I3 F47 - I3
TPS IN 4 04 I4 F47 - I4
HDMI IN 5 05 I5 F47 - I5
HDMI IN 6 06 I6 F47 - I6
HDMI IN 7 07 I7 F47 - I7
HDMI IN 8 08 I8 F47 - I8
MIC INPUT - - - - I9
 - - - - I10
<video_port_name> - - I11
TPS OUT 1 01 O1 - - O1
TPS OUT 2 02 O2 - - O2
HDMI OUT 3 03 O3 - - O3
HDMI OUT 4 04 O4 - - O4
AUDIO OUT 05 O5 - - -
 - - - - O6
RS-232 Ports
Port name
Port nr.

Command
injection port nr.
Rs232 1 P1 8001
Rs232 2 P2 8002
Uart3 Ir1 Mixed P3 8003
Uart4 Ir2 Mixed P4 8004
TPS IN 1 P5 8005
TPS IN 2 P6 8006
TPS IN 3 P7 8007
TPS IN 4 P8 8008
TPS OUT 1 P9 8009
TPS OUT 2 P10 8010
Ethernet
Port name
Port nr.

CPU P1
Control P2
Uplink TPS Out P3
Uplink TPS In P4
TPS IN 1 P5
TPS IN 2 P6
TPS IN 3 P7
TPS IN 4 P8
TPS OUT 1 P9
TPS OUT 2 P10
IR Ports
Port name
Port nr.

Command
injection port nr.
IR1 Uart3 Mixed D1 9001
IR2 Uart4 Mixed D2 9002
IR3 D3 9003
IR4 D4 9004
IR5 D5 9005
IR6 D6 9006
Relay
Port name
Port nr.
(LW2 )
Port nr.
(LW3)
Relay1 1 P1
Relay2 2 P2
Relay3 3 P3
Relay4 4 P4
GPIO
Port name
Port nr.
(LW2)
Port nr.
(LW3)
Gpio1 1 P1
Gpio2 2 P2
Gpio3 3 P3
Gpio4 4 P4
Gpio5 5 P5
Gpio6 6 P6
Ethernet
Port name
Port nr.
(LW3)
CPU P1
Control P2
Utility Ethernet P3
Utility Ethernet P4
GPIO
Port name
Port nr.
(LW2)
Port nr.
(LW3)
Gpio1 1 P1
Gpio2 2 P2
Gpio3 3 P3
Gpio4 4 P4
Gpio5 5 P5
Gpio6 6 P6




