CHARGING & STARTING SYSTEM
Page 2B-26 90-883728 JULY 2001
Flow Chart (continued)
TEST 7
a. Connect voltmeter between common engine and Test Point 1.
b. Turn ignition key to “Start” position.
No voltage reading:
Defective starter solenoid
12 Volt Reading*
Should hear solenoid click: proceed to TEST 8
TEST 8
a. Reconnect BLACK cable (with YELLOW sleeve) to starter solenoid Test
Point 1.
b. Connect voltmeter between common engine ground and Test Point 7.
c. Turn ignition key to “Start” position.
No voltage reading:
Check BLACK cable (with YELLOW
sleeve) for poor connection or open circuit.
12 Volt Reading*
If starter motor does not turn, check starter motor.
*Battery Voltage
To Next Page
