WIRING DIAGRAMS
Page 2D-64 90-883728 JULY 2001
CALIBRATION
TRIM CALIBRATION
[EDIT]
[SKIP]
CALIBRATION
TRIM FULL UP
THEN PRESS PLUS (+) BUTTON
[DFLT]
[SAVE]
[SKIP]
CALIBRATION
TRIM TO TRAILER POINT
THEN PRESS PLUS (+) BUTTON
[DFLT]
[SAVE]
[SKIP]
CALIBRATION
TRIM FULL UP
THEN PRESS PLUS (+) BUTTON
[DFLT]
[SAVE]
[SKIP]
If the trim setting is not reading correctly, the trim sensor can
be re-calibrated to correct the setting.
Pressing DFLT (default) during edit will return to original value
setting
Press MODE to skip to the next display. Press + (edit) to cali-
brate the sensor.
1. Trim outboard full up, than Press + to save.
2. Trim outboard to the point where the trim cylinders takes over,
than Press + to save.
3. Trim outboard full down, than Press + to save.
[ YES ]
[ NO ]
EXIT ?
CALIBRATION
Do you want to exit the calibration mode? Press + for yes.
Press MODE for no.
Speedometer Calibration
Simple Calibration – This calibration for setting lighting and setting the clock can be
made while engine is running.
1. Press in the
MODE
and
TROLL
+
buttons for calibration screen.
2. Press
MODE
to advance through the calibration selections.
Advanced Calibration – This calibration goes through the entire mode selections.
1. Turn ignition key to the off position.
2. Hold
TROLL
+
TROLL
–
and turn ignition key to the on position.
3. Press and hold
MODE
for 2 seconds to bring up the calibration screen.
4. Press
MODE
to advance through the calibration selections.
[DOWN]
CALIBRATION
BRIGHTNESS
[UP]
[SAVE]
Press – or + to adjust level. Press MODE to save setting
CALIBRATION
BRIGHTNESS
[ YES ]
[ NO ]
SET ALL INSTRUMENTS?
Do you want the same brightness level for all SmartCraft
gauges? Press + for yes. Press MODE for no.
[DOWN]
CALIBRATION
[UP]
[SAVE]
CONTRAST
Press – or + to adjust level. Press MODE to save setting
CONTRAST
CALIBRATION
[ YES ]
[ NO ]
SET ALL INSTRUMENTS?
Do you want the same contrast level for all SmartCraft
gauges? Press + for yes. Press MODE for no.
To Next Page
