POWERHEAD
Page 4A-18 90-883728 JULY 2001
Powerhead Removal from Driveshaft Housing
1. Disconnect battery cables from battery terminals.
2. Remove top cowling.
3. Remove two screws which secure remote control harness retainer and remove retainer.
57841
a
a
b
a-Screws
b-Retainer
4. Remove bottom cowls.
a
a
58774
58068
a
a-Bolts
