WIRING DIAGRAMS
Page 2D-50 90-883728 JULY 2001
FILL TO 1/2 THEN PRESS PLUS
BUTTON
[DFLT]
[SAVE]
[SKIP]
You can choose to have tank at 1/2 and hit SAVE, or hit DFLT and
a default value will be entered based on the capacity of the tank.
FILL TO 3/4 THEN PRESS PLUS
BUTTON
[DFLT]
[SAVE]
[SKIP]
You can choose to have tank at 3/4 and hit SAVE, or hit DFLT and
a default value will be entered based on the capacity of the tank.
[DFLT]
[SAVE]
[SKIP]
FILL TO FULL THEN PRESS PLUS
BUTTON
You can choose to have tank at full and hit SAVE, or hit DFLT and
a default value will be entered based on the capacity of the tank.
DEPTH SENSOR OFFSET
[DOWN]
[UP]
[SAVE]
Lets you electronically configure a depth offset. Entering a nega-
tive number gives you a water line offset. A positive number gives
you a keel offset.
DEPTH ALARM
[DOWN]
[UP]
[SAVE]
Lets you enter a depth value. When the depth transducer reads
that value or below, the shallow water alarm will sound.
EMPTY TANK THEN PRESS PLUS BUT-
TON
[DFLT]
[SAVE]
[SKIP]
You can choose to have an empty tank and hit SAVE, or hit DFLT
and a default value will be entered based on the capacity of the
tank.
Speedometer Calibration
Quick Cal – This calibration for setting lighting and contrast.
1. Press in the
MODE
and
TROLL
+
buttons for up to 2 seconds to get to Quick Cal screen.
2. Press
MODE
to advance through the lighting and contrast sections.
Cal1 – This calibration level lets you turn on and off the system screens. You may configure
the system to display as little or as much information as you prefer.
1. Press in the
MODE
and
TROLL
+
buttons and hold for approximately 7 seconds until you
see the calibration1 (
Cal1
) screen.
2. Press
MODE
to advance through the calibration selections.
Cal2 – This calibration level lets you configure the system sensor inputs.
1. Press in the
MODE
and
TROLL
+
buttons and hold for approximately 10 seconds for calibra-
tion2 (
Cal2
) screen.
2. Press
MODE
to advance through the calibration selections.
