FUEL INJECTION
Page 3B-54 90-883728 JULY 2001
Water Separating Filter Assembly Removal
NOTE: To inspect or replace water separator, it is not necessary to remove inlet fuel line.
1. Remove water sensor lead from bottom of separator.
2. With wipe towels available, use Strap Wrench (91-24937A1) to remove water separa-
tor.
58800
b
a
91-24937A1
a-Water Separator
b-Water Sensor Lead
Water Separating Filter Assembly Installation
IMPORTANT: Apply a light coat of outboard oil to the rectangular sealing ring on the
water separator before installation.
1. After applying oil to sealing ring of water separator, install separator onto bracket.
2. HAND TIGHTEN SEPARATOR. DO NOT use strap wrench or other tool to tighten sep-
arator.
3. Reconnect water sensor lead to bottom of separator.
