FUEL INJECTION
Page 3B-2 90-883728 JULY 2001
Specifications
FUEL
INJECTION
Idle RPM
– All Models
Wide Open Throttle (WOT) RPM
– Model 150XRI/175XRI/200XRI
Float Adjustment (Vapor Separator)
Float Level
Injectors
– All Models (Quantity)
– Injectors are Crank Angle
Driven by ECM
– #1 Cylinder
– #2 Cylinder
– #3 Cylinder
– #4 Cylinder
– #5 Cylinder
– #6 Cylinder
Line Pressure @ Injectors
Injector Resistance
Electric Fuel Pump Resistance
Electric Fuel Pump Amperage Draw
625 ± 50
5250 – 5750
Preset @ Factory
6
RED + BRN Leads
RED + WHT Leads
RED + ORG Leads
RED + YEL Leads
RED + LT. BLUE Leads
RED + PUR Leads
41 psi – 45 psi (283 kPa – 310 kPa)
12.3 ohms ± 0.5 ohms
0.7 ± 0.3 ohms
4 amperes ± 0.5 amperes
