12 Display & Cine Review
Operator’s Manual 12 - 3
• Cine files stored in the system’s hard drive shall contain patient information,
to avoid the selection of an incorrect image file and potential misdiagnosis.
12.4.1 Entering/Exiting Cine Review
To Enter Cine Review
• The system enters the manual cine review status once press <Freeze> to freeze the image.
• Open cine files in thumbnail, iStation or Review. The system enters automatic cine review
status.
To Exit Cine Review
Press <Freeze> or <B>, the system will return to image scanning and exit cine review.
12.4.2 2D Cine Review
Manual Cine Review
Enter the cine mode in 2D imaging mode. Use the trackball/trackpad to view the cine.
If you move the playback mark to the left by using the trackball/trackpad, the review sequence is
reversed to the image-storing sequence, thus the images are displayed in descending order.
Whereas, if you move the playback mark to the right by using the trackball/trackpad, the review
sequence is the same as the image-storing sequence, thus the images are displayed in ascending
order. When you review images until the first or the last frame, further using the trackball/trackpad
will display the last or first frame.
The cine progress bar at the bottom of the screen (as shown in the figure below):
Reviewing all of Auto Review
Perform the following procedure:
1. In the manual cine review status, use the [Auto Play] to set the review speed to activate auto
cine review.
2. Exit:
Tap [Auto Play] on the touch screen, or use the trackball/trackpad, the auto review state
becomes manual cine review.
1 Start mark
2Playback mark
3End mark
4 Current frame
5 Total frames
6 Auto Review Region
123
6
45
