13 - 4 Operator’s Manual
13 Measurement, Comments and Body Mark
If needed, tap [Advanced Settings] to enter comment property screen to set the arrow style/
size.
3. Press <Set> to anchor the arrow position.
Repeat steps above to add more arrows if necessary.
4.
Press <ABC> or the user-defined key for
“Arrow” to exit the arrow comment status.Trace
In comment status, tap [Advanced Settings] > [Trace] on the touch screen to activate trace function,
and the current image is also displayed on the touch screen.
Using the control panel:
1. Use the trackball/trackpad to move the cursor to a desired position, and press <Set> to confirm
the start point.
2. Use the trackball/trackpad to move the cursor along the edge of the desired region and trace the
outline of the region.
–
Rotate th
e <Angle> knob
counter
-clockwise to
cancel 1 pix
el of trace.
–
Rotate th
e <Angle> knob
clockwise to
restore 1 pix
el of trace.
– Short press <Clear> to clear last trace. Long press <Clear> to delete all tracing.
3. Press <Set> to finish the tracing.
Using the touch screen:
1. Trace around the ROI by taping the touch screen image using your finger.
2. Remove your finger to finish the tracing.
– [Clear]: tap to delete the trace in reverse order one by one.
– [Clear All]: tap to delete all traces.
3. Tap [Exit] to exit the tracing.
13.2.2 Moving Comments
If image size and position changed due to display format switching, then the position of the
comment can be changed, too.
Perform the following procedure:
1. Select the comment to be moved.
2. Use the trackball/trackpad to move the comment to the new position.
3. Press <Set> key to anchor the comment in the new position, and the comment-moving
operation is complete.
13.2.3 Editing Comments
Modifying characters
Perform the following procedure:
1. In comment status, move the cursor onto the comments to be modified.
Press alphabetic keys to enter the character to the cursor position directly.
