12 - 4 Operator’s Manual
12 Display & Cine Review
Setting scope of Auto Review
You can set a segment of cine loop which can be reviewed automatically.After the auto review
scope is set, the auto cine review can only be performed within this scope; but the manual cine
review can be performed beyond this scope. When the cine file is saved, only the images within this
scope are saved.
You can perform cine review on each image window in the dual/quad splitting mode, and set auto
review region for each window.
Perform the following procedure:
1. Set the start frame:
Manually review the cine file by trackball/trackpad, and tap [Set Begin] on the touch screen to
set current frame to be the start point.
2. Set the end frame:
Manually review the cine file by trackball/trackpad, and tap [Set End] on the touch screen to
set current frame to be end.
3. Use [Auto Play] on the touch screen to set the review speed.
The system plays the auto review region automatically.
4. Tap [Jump to First]/ [Jump to Last] to review the first or last image.
12.4.3 Cine Review in M/PW/CW/TVD Mode
Enter cine review in M mode, PW mode, CW mode TVD mode, and then use the trackball/trackpad
the cine images are displayed on the screen one by one.
Move the playback mark to the left by using the trackball/trackpad. The review progress slider
moves to the left, the images moves to the right, and the earlier stored images are invoked. Whereas
move the playback mark to the right by using the trackball/trackpad, the review progress slider
moves to the right, and the images move to the left, the recently stored images are invoked. When
the image goes to the first/last frame, the cine is played in loop with the trackball/trackpad moving
left or right.
The cine progress bar at the bottom of the screen (as shown in the figure below):
Cine review operations are the same as these of 2D mode.
1Start mark
2 Playback mark
3End mark
4 Time played
5Total time
6 Auto Review Region
123
6
45
