A - 14 Operator’s Manual
A Barcode Reader
a. Scan the following 1-D barcode to configure the barcode reader:
b. Scan the following 1-D barcode to enable the suffix:
c. Scan the following 1-D barcode to disable the prefix:
A.4 Maintenance
Cleaning the exit window is the only maintenance required. A dirty window can affect scanning
accuracy.
• Do not allow any abrasive material to touch the window.
• Remove any dirt particles with a damp cloth.
• Wipe the window using a tissue moistened with ammonia/water.
• Do not spray water or other cleaning liquids directly into the window.
A.5 Parameter Defaults
Refer to the following table for parameter defaults of LS2208 and DS4308.
Parameter Defaults Parameter Defaults
1-D Symbologies Interleaved 2 of 5 (ITF)
UPC/EAN Interleaved 2 of 5 (ITF) Enable Enable
UPC-A Enable Set Lengths for I 2 of 5 14
UPC-E Enable I 2 of 5 Check Digit Verification Disable
UPC-E1 Disable Transmit I 2 of 5 Check Digit Disable
EAN-8/JAN 8 Enable Convert I 2 of 5 to EAN 13 Disable
