13 Measurement, Comments and Body Mark
Operator’s Manual 13 - 5
Or, double press <Set> to enter comment editing status, and use the direction-control keys to
move the cursor to the desired location to insert/delete characters; you can either type
characters by pressing the corresponding keys or select the new comment text from the menu.
2. Press <Del> to delete the comment character or text on the right side of the cursor; press
<Back> to delete the comment character or text on the left side of the cursor.
3. Press <Set> key, or move the cursor to confirm the added comments text and exit the edit
status.
If there are already comments on the screen, press the space bar to enter editing status.
Modifying Arrows
Perform the following procedure:
1. Move the cursor on the arrow that needs to be modified. After the cursor becomes , press
<Set>. There is a frame around the arrow, indicating the arrow can be edited. Move the cursor
to change the arrow position.
2.
Rotate
the <Angle> kn
ob to modif
y the arrow’
s di
rection.
3. Press <Set> key to complete the operation.
13.2.4 Deleting Comments
Deleting Comments Characters, Texts or Arrows
Perform the following procedure:
1. Move the cursor to the comments to be deleted.
2. Press <Set> to select the comment.
3. Tap [Delete Word] or press <Clear> to complete the deletion.
Deleting a recently-added character, text or arrow
In comment status, press <Clear> to delete the latest added/modified comment unit.
Enter letters by pressing the alphanumeric key on the keyboard and use blank key to divide the
letters. Tap [Delete Word] to delete latest added/modified comment unit and enter comment status.
Delete letters one by one
In comment editing status, tap <Back> to delete letters before cursor “|”.
In comment editing status, tap <Del> to delete letters after cursor “|”.
In comment status, enter letters by pressing the alphanumeric key on the keyboard. Tap [Delete
Word] to delete letters before cursor “|”.
Erase All Text
• When no item is selected, press <Clear> will clear all comments and all measurements
calipers.
• After powering off, the system will clear all comments on the image.
Long press <Clear> key to delete all the comments.
13.2.5 Setting the Start Position
Perform the following procedure:
