4 - 24 Operator’s Manual

4 Setup

TIP:

You can only delete the user-defined items rather than the items in the system library. After a user-

defined item is deleted, it will not be available.

Change position of the selected items

Select an item on the right side box and click [Up], [Down], [Left] or [Right] button to change the

position of the item.

4.4.2 Comment Group Define

Add user-defined group

Enter user-defined group name in the name text box below [Lists Name] through the soft keyboard,

click [Add Group]. The entered group name will be added to the Group Lists.

Add comment items to the user-defined group

Perform the following procedure:

1. Select a user-defined comment group from the “Group Lists”.

2. Do one of following to add comment items:

– Select a comment library in the drop-down list below “Application”: Select a comment

item, click [>] to add it into Selected Items on the right; click [>>] to add all items into

Selected Items on the right directly

– Add user-defined comment item: Enter user-defined comment in the name text box above

[Add Comment] through the soft keyboard, click [Add Comment]. The entered comment

item will be added to the Selected Items.

Change position of the selected items

Select an item and click [Up], [Down] button to change the position of the item.

Delete a comment item from user-defined group

Select an item in the Selected Items, click [<].

TIP:

You can only delete the user-defined items rather than the items in the system library. After a user-

defined item is deleted, it will not be available.

4.5 iWorks Preset

You can customize the protocols and views in the iWorks preset screen.

4.5.1 Protocol Management

• Click to select the protocol in the list. The protocol type can be checked on the right.

• Click [Add Protocol] to create a new protocol. It can be customized.

• Click to select a protocol in the list on the left and click [Copy]. A protocol named

“XXX_Copy1” is created with the copied views, which can be customized.

• Select a view with “Left”, “Lt”, “Right” or “Rt” in its name in the list on the left, and click

[Copy L<>R]. The selected view is copied onto a new view in which bodymarks, annotations

and measurement items are reversed to the opposite side.
