3Explanation of operation methods
Operating the monitor screen 3-75
(2) Output signal monitor
There are the function which always makes the ON/OFF state of the output signal the monitor, and the func-
tion outputted compulsorily.
1) Press the [2] key in the monitor menu screen, and display the output signal screen. The output signal
of the 32 points can be monitored on the one screen.
The case where the state of the output signals 8-15 is confirmed is shown in the following.
2) Press the function key corresponding to "Number".
Set "8" as the start number.
Although the state of the current output signal is displayed on the output value on the display, it is not always
the display here in the section which sets up the compulsive output value of the signal.
Press the function key corresponding to "CLOSE". Display the ON/OFF state of the 32 points at the head for
the output signal No. 8. Black painting indicates ON and white indicates OFF.
Press the function key corresponding to "Next", then display the next output signal screen. Press the func-
tion key corresponding to "Prev", then display the previous output screen.
<OUTPUT>
5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0
15 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 0
31 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 16
1 0 9 8 7 6 5 4 3 2 1 0 9 8 7 6
NUMBER
CLOSE
123
Next Prev
<MONITOR>　　 　
1.INPUT
2.OUTPUT
3.INPUT REG. 4.OUTPUT REG.
5.VARIABLE 6.ERROR LOG
CLOSE
　 123
<OUTPUT>
START No. （ 8_ )
5432109876543210
OUT.VALUE （0000000000000000）
CLOSE
123
OUTPUT
<OUTPUT>
5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0
15 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 0
31 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 16
1 0 9 8 7 6 5 4 3 2 1 0 9 8 7 6
NUMBER
CLOSE
123
Next Prev
<OUTPUT>
3 2 1 0 9 8 7 6 5 4 3 2 1 0 9 8
23 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 8
39 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 24
9 8 7 6 5 4 3 2 1 0 9 8 7 6 5 4
NUMBER
CLOSE
123
Next Prev
<OUTPUT>
5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0
55 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 40
71 5 4 3 2 1 0 9 8 7 6 5 4 3 2 1 0 56
1 0 9 8 7 6 5 4 3 2 1 0 9 8 7 6
NUMBER
CLOSE
123
Next Prev
