3-48
Programming 15088:J 10/22/99
2=UNP - Unprogrammed Device Report
3=UNI - Uninstalled Device Report
4=TEST - Tested Device Report
5=UNTST - Untested Device Report
These options allow the programmer to generate the desired Walk Test report. These reports are generated
on a LIB basis. They use the same display format as the Point Read option under Read Status except for the
status field which is report-specific (no Control-by-Event or annunciator point mapping is reported). The
results of the report are not displayed on the CRT screen but are printed out on the printer.
1=REQUEST Begins the selected report.
2=ABORT Aborts the selected report in progress.
NOTE
Only one report can be conducted at any one time.
WARNING:Do not reset the Control Panel while in Walk Test mode. Execution of a System Reset during a
Walk Test may cause unwanted activation of various output modules (CMX, XPC, etc.). If a Sys-
tem Reset occurs during a Walk Test, exit Walk Test Mode and re-enter.
The following CRT screen illustrates conducting a Tested Device Report. The printout of this test is illustrated
in Figure 2-3.
PRESS@1=SEL,2=UNP,3=UNI,4=TEST,5=UNTST,6=EXIT@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@:@4
ENTER@LIB@NUMBER@FOR@WALK@TEST@REPORT@(1@-@10) :@1
PRESS@1=REQUEST,2=ABORT@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@:@1
LIB@01@TESTED@DEVICE@REPORT@BEGIN@@@@@@@@@@@@@@@@@@@@@@@@@@@@04:32P@03/01/00
NOTIFIER@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@ALL@SYSTEMS@NORMAL@@04:32P@03/01/00
LIB@01@TESTED@DEVICE@REPORT@END@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@04:32P@03/01/00
NOTIFIER@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@ALL@SYSTEMS@NORMAL@@04:32P@03/01/00
6=EXIT - Exit Walk Test C |X6X6X
This option allows the programmer to exit/abort Walk Test. In order to exit/abort Walk Test Mode, reenter
Alter Status Mode and choose option 6 from the Walk Test submenu.
The following example demonstrates exiting/aborting Walk Test:
PRESS@1=SEL,2=UNP,3=UNI,4=TEST,5=UNTST,6=EXIT@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@@:@6
NOTE
Upon exiting/aborting Walk Test, the Walk Test system trouble is cleared and the AM2020/AFP1010
resumes full fire protection.
C | X6X(2,3,4 or 5)X
