Notifier AM2020 User Manual

3-54
Programming 15088:J 10/22/99
Group 3: Software Zones
• A Forward-Activating Zone is a software zone in control panel memory which once activated by an
addressable input device or other forward zone may in turn activate other zones and/or addressable
output devices directly. Zones and output devices activated by a forward zone are contained in the CBE
List of that forward zone, or the zone may be listed in the CBE of the addressable output device.
• A Reverse-Activating Zone is a software zone in control panel memory which if not activated directly
by an addressable input device or forward zone may be activated through an associated CBE equation.
A Reverse Zone may be listed in other CBE Equations.
Type of Device
A software-defined zone that is forward-activating .
A software-defined zone that is reverse-activating.
Type ID
FZON
RZON
Display Label
FORWARD ZONE
REVERSE ZONE
Type of Device
MMX Monitor Module, an XPM-8 circuit, or an XP5-M circuit used to
monitor normally-open contact, shorting-type devices other than 4-wire
smoke detectors (i.e. conventional heat detectors, pull stations, etc.).
BGX-101L Addressable Manual Pull Station.
MMX Monitor Module, an XPM-8 circuit, or an XP5-M circuit used to
monitor normally-closed contact, opening-type devices.
MMX Monitor Module, an XPM-8 circuit, or an XP5-M circuit that
functions identically to Software Type ID NONA with one exception -
subsequent alarms from this Type ID will not reactivate silenced output
devices - once silenced, outputs will remain silenced until reactivated by
another Software Type ID (or cleared by System Reset and reactivated).
MMX Monitor Module, an XPM-8 circuit, or an XP5-M circuit used to
monitor normally-open contact, shorting-type non-alarm devices. Activa-
tion of a module with Software Type ID NONA will not initiate a fire alarm
condition:
• System Alarm LED will not illuminate.
• Does not activate alarm status line count on a CRT.
• No affect on modules programmed as APND (alarm pending)
or GPND (general event pending).
• Alarm, clear alarm, or acknowledgments are not reported for
this type.
BGX-10 Addressable Manual Pull Station.
MMX Monitor Module or an XP5-M circuit used to monitor conventional
4-wire smoke detectors. This module has a longer reset period than
modules programmed as MON.
MMX Monitor Module, an XPM-8 circuit, or an XP5-M circuit dedicated
to a Water Flow Alarm device.
Type ID
MON
MPUL
NCMN
NOA
NONA
PULL
SCON
WAT
Display Label
MONITOR
MON PULL STA
MON NORM CLD
NON ALARM
NON ALM MON
PULL STATION
SMOKE (CONV)
WATER FLOW
Group 4: Alarm Initiation Modules
