Notifier AM2020 User Manual

4-19
Security 15088:J 10/22/99
Control Module for Ringback (See Figure 1.3-11)**
NIB-96
Installed in an ICA-4 or ICA-4L in an AM2020/AFP1010
Protected Premises Unit. For further information refer
to Chapter Two, Programming of this manual and the
Network Interface Board (NIB-96) manual.
LIB-200, LIB-200A,
or LIB-400
in Central Station
SIB-2048A or SIB-NET
Installed in an
AM2020/AFP1010
Protected Premises Unit
Central Station/Protected Premises Unit Wiring
LIB-200, LIB-200A,
or LIB-400
Installed in an
AM2020/AFP1010
Protected Premises
Unit
Figure 1.3-10 Single Tenant Security System with Ringback
Key
Motion Detector
Contact Switch
CM
TENANT A
Contact Switch w/MM
MM Security Area Monitor
RKS-S Remote Keyswitch w/MM
Pull Station
Smoke Detector
Group Interface
*
ACM-16AT or ACM-32A Remote Annunciator
* Group Interface must be physically located in
either the protected premises or the Central Station
CM
MM
NIB-96 NIB-96 Network Interface Board
RA400Z Remote Annunciator (see Figure 1.3-11)
**
**
Must be physically located in the protected
premises and the RA400Z must be visible from
outside the protected area to provide visible
indication that the central station has received
the arming signal from the PPU.
STS-1 Tamper Switch with Monitor Module (See Fig 1.3-13)
CMMM
CM
NIB-96
AM2020/AFP1010
Central Station
AM2020/AFP1010
PPU
See Central Station/PPU Wiring Diagram below
Signaling Line Circuit
from Central Station
Area9.cdr
AREA 1
(Perimeter
and
Interior)
**
**
*
