Omron E5*C Series User Manual

6 - 21
6 Parameters
E5@C-T Digital Temperature Controllers User’s Manual (H185)
6-4 Program Setting Level
6
These parameters are used to set the alarm upper limits and alarm lower limits for alarms for which
upper/lower limits have been selected in Alarm 1 Type to Alarm 4 Type (initial setting level).
al1h
Alarm Upper Limit 1
Alarms 1 to 4 must be assigned.
The alarm 1 to 4 type must be set to 1, 4, or 5.
al2h
Alarm Upper Limit 2
al3h
Alarm Upper Limit 3
al4h
Alarm Upper Limit 4
al1l
Alarm Lower Limit 1
al2l
Alarm Lower Limit 2
al3l
Alarm Lower Limit 3
al4l
Alarm Lower Limit 4
• These parameters set the upper limits and lower limits for alarms 1 to 4 of the specified
program number.
• For a temperature input, the decimal point is automatically set according to the selected
sensor. For an analog input, the decimal point is set according to Decimal Point
parameter setting.
z Related Parameters
Input Type (Initial Setting Level): Page 6-56
Scaling Upper Limit, Scaling Lower Limit, Decimal Point (Initial Setting Level): Page 6-57
Alarm 1 to 4 Type (Initial Setting Level): Page 6-66
Alarm 1 to 4 Hysteresis (Initial Setting Level): Page 6-70
Standby Sequence Reset (Advanced Function Setting Level): Page 6-83
Auxiliary Output 1 to 4 Open in Alarm (Advanced Function Setting Level): Page 6-84
Alarm 1 to 4 Latch (Advanced Function Setting Level): Page 6-89
Function
Setting
Setting range Unit Default
−1999 to 9999 EU 0
See
See
