Refer to 5-7 Exposing Variables to Standard Controllers
on page 5 - 30 for details on registering
exposed variables.
l
Editing Global Variables
1 Click the cell to edit for the registered variable.
You can use the autocompletion to enter a data type in the Data Type cells. When you enter
the first letter (example: S), a list of data types that begin with the letter is displayed. Select a
data type from the list.
2 Change the value or the settings, and then press the Enter key.
The change is applied to the variable.
• Entry candidates you can select are displayed as follows:
Entry candidates are displayed in the Name, Data Type, and Initial V
alue cells.
Entry candidates that match the characters in the entered text string are displayed as you edit
the text string.
• Entry candidates you can select by drag and drop are displayed as follows:
You can move the position at which the selected variable is defined. You cannot select multiple
variables.
If you select multiple variables, the variable at the very bottom row will be the target of the drag
and drop operation.
l
Deleting Global Variables
1 Click any cell on the line of the variable to delete to select the entire line.
2 Press the Delete Key. Or
, right-click a row and select Delete from the menu.
6 Programming
6 - 38
NX-series Safety Control Unit User's Manual (Z930)
