The following table shows values set to input variables of the function block.
Input variable name Setting value
Activate TRUE
S_StartReset FALSE
S_AutoReset Value specified for the reset type
Manual: F
ALSE
Auto: TRUE
Reset V
ariable generated in the reset signal generation step
MonitoringTime t#300ms
Any other input variables Variable automatically generated based on the following naming rule:
FB Instance Name_Input V
ariable Name
2
3
TRUE
EMO_NC_S1
FALSE
FALSE
Reset_S2_Out
Activate
S_EStopIn
S_StartReset
S-AutoReset
Reset
Ready
S_EStopOut
Error
DiagCode
EMO_NC_S1_Out
SF_EmergencyStop
SF_EmergencyStop_0
Emergency Stop Pushbutton S1
TRUE
LaserScanner_S3
FALSE
TRUE
Reset_S2_Out
Activate
S_ESPE_In
S_StartReset
S-AutoReset
Reset
Ready
S_ESPE_Out
Error
DiagCode
LaserScanner_S3_Out
SF_ESPE
SF_ESPE_0
Safety Laser Scanner S3
l
Generation of Logical Operation Circuit
At this step, an AND logic function is generated for each output variable based on the Expected
Value Settings in the Automatic Programming Settings T
ab Page.
The internal variables, which are automatically generated at the input signal generation, are used
as input variables for the AND function. In addition, the output variable of the AND function is auto-
matically generated as an internal variable and is used as an input signal at the following output
signal generation.
6 Programming
6 - 69
NX-series Safety Control Unit User's Manual (Z930)
6-6 Automatic Programming
6
6-6-1 Generation Algorithms for Automatic Programming
