Onan MicroLite 4000 Series User Manual

4-2
TABLE 4-2. GENERATOR TORQUE SPECIFICATIONS
ITEM POUND - FEET NEWTON - METERS
Rotor Through-Bolt 40-50 54-68
Stator Through-bolt 5-8 7-11
Endbell to Stator Housing 5-8 7-11
Mount Assy. Bolt (Spec A) 38-43 52-58
Mount Assy. Bolt
(Begin Spec B) 35-40 47-53
Stator Housing to
Engine Block 15-18 21-24
TABLE 4-3. METRIC BOLT TORQUE SPECIFICATIONS - NO GRADE OR 8.8 GRADE
SIZE POUND - FEET NEWTON - METERS
M6 6 - 7 8 - 9
M8 13 - 15 18 - 21
M10 29 - 33 39 - 45
M12 46 - 54 63 - 73
TABLE 4-4. METRIC BOLT TORQUE SPECIFICATIONS - 10.9 GRADE
SIZE POUND - FEET NEWTON - METERS
M6 7 - 8 10 - 11
M8 17 - 20 24 - 27
M10 35 - 41 48 - 56
M12 57 - 67 77 - 90
